ABUTTING HIGHWAY ROAD DETAILS Adjoining the 6-lane State Highway TOWNSHIP MAIN ENTRY ROAD FROM HIGHWAY 100 feet BT Road with pavered walkways on either sides, designed as per Clause-406 of MORTH either sides with landscaped mounds PLOTTED AREA MAIN ROAD 60 feet BT Road with pavered walkways on either sides designed as per Clause-406 of MORTH PLOTTED AREA INTERNAL ROADS 40', 30' & 25' BT/Paver Road STORM WATER DRAIN - MAIN ROAD RCC Box Culvert, M25 Gr-150mm thick RCC wall designed for maximum flood water discharge STORM WATER DRAIN - INTERNAL ROAD Hume Pipe Culvert, NP3 Culvert with maximum flood water discharge CABLE TRENCH FOR HT & LT - MAIN ROAD RCC Box Culvert, M25 Gr-150mm thick RCC wall designed to depth of 6' to have separate for LT & HT lines CABLE TRENCH FOR HT & LT - INTERNAL ROAD Hume Pipe Culvert, NP3 Culvert to have LT lines SEWAGE LINE Well designed uPVC lines with conical chambers to carry maximum sewage flow WATER SUPPLY LINE Well designed uPVC lines with inspection chambers WASTE WATER LINES Well designed uPVC lines with conical chambers to carry maximum flow STP CONNECTIVITY Provision for Ultra Modern STP Unit with ACF followed by UV system WTP CONNECTIVITY Provision for WTP Unit with ACF followed by UV system PAVERED WALKWAY M35 Gr shot blasted paver 40mm thick STREET LIGHTS ON MAIN ROADS AND INTERNAL ROADS Well designed & elegant street light poles with LED fittings FIRE HYDRANT LINES Fire Hydrant pipe lines with double head hydrant valves and hose reels in suitable location COMMUNICATION LINES Well designed Fibre Optical Cables from Telecom services LANDSCAPING Well designed landscaping in OSR and also for each plot INFRA CONSULTANT Mott Mcdonald - International Infrastructural Consultant
